| Specification | |||
| Voltage(DCV) | 600.0mV | ±(0.3%+5) | |
| 6.000V/60.00V/600.0V | ±(0.2%+5) | ||
| 2500V | ±(1.0%+5) | ||
| Voltage(ACV) | 45～1kHz | 600.00mV/6.000V/60.00V/600.0V/1500V | ≥45Hz, <500Hz: ±(0.8%+3); |
| ≥500Hz, <1KHz: ±(1.8%+3); | |||
| VFD (ACV) | 45～200Hz | 600.0V/1500V | ±(2.0%+5) |
| Auto Loz | 45～400Hz | 600.0V | ±(1.5%+5) |
| 1500V | ±(1.8%+5) | ||
| ACV+DCV | 600.00mV/6.000V/60.00V/600.0V/1500V | ≥45Hz, <500Hz: ±(1.5%+5); ≥500Hz, <1KHz: ±(2.5%+5); |
|
| Resistance | 600.0Ω | ±(0.8%+5) | |
| 6.000kΩ/60.00kΩ/600.0kΩ/ 6.000MΩ |
±(0.5%+5) | ||
| 60.00MΩ | ±(2.5%+5) | ||
| Capacitance | 60.00nF | ±3.0% | |
| 600.0nF/6.000μF/60.00μF/ 600.0μF |
±(3.0%+5) | ||
| 6.000mF/60.00mF | ±(10.0%+5) | ||
| Continuity | 600.0Ω | ±(1.0%+5) | |
| Diode | 3.2V | ±(1.0%+5) | |
| Fequency | 99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz | ±(0.02%+5) | |
| Duty cycle | 10Hz~10KHz (10%~90%) | ±(2.0%+30) | |
| Temperature | -40℃~1000℃ | ±(1.0%+30) | |
| -40℉~1832℉ | ±(1.0%+60) | ||
| External clamp (DCA) | UT-CS07(optional) | 100A(10mV/A) & 1000A(1mV/A) | ±(0.8%+5) |
| External clamp (ACA) | UT-CS07(optional) | 45～400Hz: 100A(10mV/A) & 1000A(1mV/A) | ±(1.0%+5) |
| AC Power 100A(10mV/A) | Active power | 60.00kW/150.0kW | ±(3.0%+5) |
| Apparent power | 60.00kVA/150.0kVA | ±(2.0%+5) | |
| Reactive power | 60.00kVAr/150.0kVAr | ±(5.0%+5) | |
| Factor | -1~1 | * | |
| AC Power 1000A(1mV/A) | Active power | 600.0kW/1500kW | ±(3.0%+5) |
| Apparent power | 600.0kVA/1500kVA | ±(2.0%+5) | |
| Reactive power | 600.0kVAr/1500kVAr | ±(5.0%+5) | |
| Factor | -1~1 | * | |
| DC Power 100A (10mV/A) | 60.00kVA/250.0kVA | ±(3.0%+5) | |
| DC Power 1000A (10mV/A) | 60.00kVA/2500kVA | ±(3.0%+5) | |
| Display count | 6000 | ||
| Analog bar | 33 segment | ||
| True RMS | √ | ||
| NCV | √ | ||
| Auto range | √ | ||
| REL. | √ | ||
| PEAK | √ | ||
| MAX/MIN | √ | ||
| Data hold | √ | ||
| High voltage alarm | √ | ||
| High voltage OL alarm | √ | ||
| Low battery indication | √ | ||
| Auto power off | √ | ||
| Multifunctional protection | √ | ||
| Bluetooth app | √ | ||
| Backlight | Auto backlight | ||
| Drop protection | 5m | ||
| IP rating | IP67 | ||
| Working temperature | -40~55℃ | ||
| Overvoltage category | CATⅣ1000V & CATⅢ1500V | ||
